Problems installing TANGO on Ubuntu 14.04

The following issue started as an email exchange :

Dear Andy.

Thanks for tube link. I watched the video 3 or 4 times.

After many-many times trying to install Tango, last night it successfully running. But, when I restart my computer, same error of the db server occur and occur again. last installation of the Tango was on fresh Ubuntu 14.04 LTS.
trying to solve with:

export TANGO_HOST=rifai-System-Product-Name:10000

the error remains. Do you have any solver for this problem?.

with best regards,
Rifai

On Monday, May 18, 2015 6:26 PM, Andrew GOETZ andy.gotz@esrf.fr wrote:

Dear Rifai,

how are you installing TANGO? Do you use the Ubuntu packages to do this? Have you checked out this video (French with English sub-titles):

It is very simple using the Ubuntu packaging system. If you have a question you can always post to the forum or mailing list.

Kind regards

Andy

On 18/05/2015 13:05, Jean-Michel CHAIZE wrote:
Dear Rifai,

Welcome in the community!
I asked you some details because your email yahoo.com doesn’t give any indication on your affiliation and we worry about false requests.
The problem you described may be due to the TANGO_HOST environment variable or the database server. Have you started the database server on your PC, on which port?
Have you set the TANGO_HOST environment variable to your_database_hostname:10000

Cheers
Jean-Michel

On 18/05/2015 07:55, rifai muslih wrote:

Tango,
Dear Jean.

Thanks for your e-mail.
I’m trying to run Tango on my Ubuntu desktop. Sorry to say, so far, I not yet succeed. It seems the problem is in the mysql server.
I’m instrument scientist of neutron diffractometer strain scanner. National Nuclear Energy Agency of Indonesia is my institute. I’m trying to implement Tango for monitoring and controlling my instrument as well as all supporting facilities which is installed remotely from my working desk.
I’m very happy if some one could share how to install and test Tango. trying to follow the instruction on Tango’s web page, same error alway got as attached.

with best regards,
Rifai

Dear RIfai,

the problem could be due to a number of reasons e.g. network setup, mysql installation, tango installation.

In order to understand we need to know what you have done and what the error is. Could you please check the following:

(1) Have you installed the tango packages as described in the instructions here:

http://www.tango-controls.org/downloads/binary/

(2) Have you installed mysql-server? Can you run mysql tango? What password has been configured?

(3) Check the user+password in /var/lib/tango/.my.cnf are the same as the one you have configured for mysql (you need to be root to do this)

(4) What is in /etc/tangorc

(5) What is your network configuration? You can check by running ifconfig

Send us your results so we can help you solve this problem.

Kind regards

Andy

Dear Andy,

Last installation was follow instruction on tube link. it perfect work just after installation.

following is the result when running your suggestion:

1 to 3
rifai@rifai-System-Product-Name:~$ sudo apt-get install mysql-server
[sudo] password for rifai:
Reading package lists… Done
Building dependency tree
Reading state information… Done
mysql-server is already the newest version.
0 upgraded, 0 newly installed, 0 to remove and 727 not upgraded.
rifai@rifai-System-Product-Name:~$ sudo apt-get install tango-db tango-test
Reading package lists… Done
Building dependency tree
Reading state information… Done
tango-db is already the newest version.
tango-test is already the newest version.
0 upgraded, 0 newly installed, 0 to remove and 727 not upgraded.
rifai@rifai-System-Product-Name:~$ sudo apt-get python-pytango
E: Invalid operation python-pytango
rifai@rifai-System-Product-Name:~$ sudo apt-get python3-pytango
E: Invalid operation python3-pytango
rifai@rifai-System-Product-Name:~$ sudo gedit /var/lib/tango/.my.cnf

#BEGIN CONFIG INFO
#DESCR: 4GB RAM, InnoDB only, ACID, few connections, heavy queries
#TYPE: SYSTEM
#END CONFIG INFO

This is a MySQL example config file for systems with 4GB of memory

running mostly MySQL using InnoDB only tables and performing complex

queries with few connections.

You can copy this file to /etc/my.cnf to set global options,

mysql-data-dir/my.cnf to set server-specific options

(/usr/local/mysql/data for this installation) or to

~/.my.cnf to set user-specific options.

In this file, you can use all long options that a program supports.

If you want to know which options a program supports, run the program

with the “–help” option.

More detailed information about the individual options can also be

found in the manual.

The following options will be read by MySQL client applications.

Note that only client applications shipped by MySQL are guaranteed

to read this section. If you want your own MySQL client program to

honor these values, you need to specify it as an option during the

MySQL client library initialization.

[client]
password = tyR9LRDjdCSj

port = 3306
socket = /var/run/mysqld/mysqld.sock

*** Application-specific options follow here ***

The MySQL server

[mysqld]

generic configuration options

port = 3306
socket = /var/run/mysqld/mysqld.sock

back_log is the number of connections the operating system can keep in

the listen queue, before the MySQL connection manager thread has

processed them. If you have a very high connection rate and experience

“connection refused” errors, you might need to increase this value.

Check your OS documentation for the maximum value of this parameter.

Attempting to set back_log higher than your operating system limit

will have no effect.

back_log = 50

Don’t listen on a TCP/IP port at all. This can be a security

enhancement, if all processes that need to connect to mysqld run

on the same host. All interaction with mysqld must be made via Unix

sockets or named pipes.

Note that using this option without enabling named pipes on Windows

(via the “enable-named-pipe” option) will render mysqld useless!

#skip-networking
#bind-address = 160.103.10.102

The maximum amount of concurrent sessions the MySQL server will

allow. One of these connections will be reserved for a user with

SUPER privileges to allow the administrator to login even if the

connection limit has been reached.

max_connections = 100

Maximum amount of errors allowed per host. If this limit is reached,

the host will be blocked from connecting to the MySQL server until

“FLUSH HOSTS” has been run or the server was restarted. Invalid

passwords and other errors during the connect phase result in

increasing this value. See the “Aborted_connects” status variable for

global counter.

max_connect_errors = 10

The number of open tables for all threads. Increasing this value

increases the number of file descriptors that mysqld requires.

Therefore you have to make sure to set the amount of open files

allowed to at least 4096 in the variable “open-files-limit” in

section [mysqld_safe]

table_cache = 512

Enable external file level locking. Enabled file locking will have a

negative impact on performance, so only use it in case you have

multiple database instances running on the same files (note some

restrictions still apply!) or if you use other software relying on

locking MyISAM tables on file level.

#external-locking
skip-locking

The maximum size of a query packet the server can handle as well as

maximum query size server can process (Important when working with

large BLOBs). enlarged dynamically, for each connection.

max_allowed_packet = 1M

The size of the cache to hold the SQL statements for the binary log

during a transaction. If you often use big, multi-statement

transactions you can increase this value to get more performance. All

statements from transactions are buffered in the binary log cache and

are being written to the binary log at once after the COMMIT. If the

transaction is larger than this value, temporary file on disk is used

instead. This buffer is allocated per connection on first update

statement in transaction

#binlog_cache_size = 32K

Maximum allowed size for a single HEAP (in memory) table. This option

is a protection against the accidential creation of a very large HEAP

table which could otherwise use up all memory resources.

#max_heap_table_size = 64M

Sort buffer is used to perform sorts for some ORDER BY and GROUP BY

queries. If sorted data does not fit into the sort buffer, a disk

based merge sort is used instead - See the “Sort_merge_passes”

status variable. Allocated per thread if sort is needed.

sort_buffer_size = 8M

This buffer is used for the optimization of full JOINs (JOINs without

indexes). Such JOINs are very bad for performance in most cases

anyway, but setting this variable to a large value reduces the

performance impact. See the “Select_full_join” status variable for a

count of full JOINs. Allocated per thread if full join is found

#join_buffer_size = 8M

How many threads we should keep in a cache for reuse. When a client

disconnects, the client’s threads are put in the cache if there aren’t

more than thread_cache_size threads from before. This greatly reduces

the amount of thread creations needed if you have a lot of new

connections. (Normally this doesn’t give a notable performance

improvement if you have a good thread implementation.)

thread_cache_size = 32

This permits the application to give the threads system a hint for the

desired number of threads that should be run at the same time. This

value only makes sense on systems that support the thread_concurrency()

function call (Sun Solaris, for example).

You should try [number of CPUs]*(2..4) for thread_concurrency

thread_concurrency = 8

Query cache is used to cache SELECT results and later return them

without actual executing the same query once again. Having the query

cache enabled may result in significant speed improvements, if your

have a lot of identical queries and rarely changing tables. See the

“Qcache_lowmem_prunes” status variable to check if the current value

is high enough for your load.

Note: In case your tables change very often or if your queries are

textually different every time, the query cache may result in a

slowdown instead of a performance improvement.

query_cache_size = 64M

Only cache result sets that are smaller than this limit. This is to

protect the query cache of a very large result set overwriting all

other query results.

query_cache_limit = 1M

Minimum word length to be indexed by the full text search index.

You might wish to decrease it if you need to search for shorter words.

Note that you need to rebuild your FULLTEXT index, after you have

modified this value.

#ft_min_word_len = 4

If your system supports the memlock() function call, you might want to

enable this option while running MySQL to keep it locked in memory and

to avoid potential swapping out in case of high memory pressure. Good

for performance.

#memlock

Table type which is used by default when creating new tables, if not

specified differently during the CREATE TABLE statement.

default_table_type = MYISAM

Thread stack size to use. This amount of memory is always reserved at

connection time. MySQL itself usually needs no more than 64K of

memory, while if you use your own stack hungry UDF functions or your

OS requires more stack for some operations, you might need to set this

to a higher value.

#thread_stack = 192K

Set the default transaction isolation level. Levels available are:

READ-UNCOMMITTED, READ-COMMITTED, REPEATABLE-READ, SERIALIZABLE

#transaction_isolation = REPEATABLE-READ

Maximum size for internal (in-memory) temporary tables. If a table

grows larger than this value, it is automatically converted to disk

based table This limitation is for a single table. There can be many

of them.

tmp_table_size = 64M

Enable binary logging. This is required for acting as a MASTER in a

replication configuration. You also need the binary log if you need

the ability to do point in time recovery from your latest backup.

#log-bin=mysql-bin

If you’re using replication with chained slaves (A->B->C), you need to

enable this option on server B. It enables logging of updates done by

the slave thread into the slave’s binary log.

#log_slave_updates

Enable the full query log. Every query (even ones with incorrect

syntax) that the server receives will be logged. This is useful for

debugging, it is usually disabled in production use.

#log

Print warnings to the error log file. If you have any problem with

MySQL you should enable logging of warnings and examine the error log

for possible explanations.

#log_warnings

Log slow queries. Slow queries are queries which take more than the

amount of time defined in “long_query_time” or which do not use

indexes well, if log_long_format is enabled. It is normally good idea

to have this turned on if you frequently add new queries to the

system.

#log_slow_queries

All queries taking more than this amount of time (in seconds) will be

trated as slow. Do not use “1” as a value here, as this will result in

even very fast queries being logged from time to time (as MySQL

currently measures time with second accuracy only).

#long_query_time = 2

Log more information in the slow query log. Normally it is good to

have this turned on. This will enable logging of queries that are not

using indexes in addition to long running queries.

#log_long_format

The directory used by MySQL for storing temporary files. For example,

it is used to perform disk based large sorts, as well as for internal

and explicit temporary tables. It might be good to put it on a

swapfs/tmpfs filesystem, if you do not create very large temporary

files. Alternatively you can put it on dedicated disk. You can

specify multiple paths here by separating them by “;” - they will then

be used in a round-robin fashion.

#tmpdir = /tmp

*** Replication related settings

Unique server identification number between 1 and 2^32-1. This value

is required for both master and slave hosts. It defaults to 1 if

“master-host” is not set, but will MySQL will not function as a master

if it is omitted.

server-id = 1

Replication Slave (comment out master section to use this)

To configure this host as a replication slave, you can choose between

two methods :

1) Use the CHANGE MASTER TO command (fully described in our manual) -

the syntax is:

CHANGE MASTER TO MASTER_HOST=, MASTER_PORT=,

MASTER_USER=, MASTER_PASSWORD= ;

where you replace , , by quoted strings and

by the master’s port number (3306 by default).

Example:

CHANGE MASTER TO MASTER_HOST=‘125.564.12.1’, MASTER_PORT=3306,

MASTER_USER=‘joe’, MASTER_PASSWORD=‘secret’;

OR

2) Set the variables below. However, in case you choose this method, then

start replication for the first time (even unsuccessfully, for example

if you mistyped the password in master-password and the slave fails to

connect), the slave will create a master.info file, and any later

changes in this file to the variable values below will be ignored and

overridden by the content of the master.info file, unless you shutdown

the slave server, delete master.info and restart the slaver server.

For that reason, you may want to leave the lines below untouched

(commented) and instead use CHANGE MASTER TO (see above)

required unique id between 2 and 2^32 - 1

(and different from the master)

defaults to 2 if master-host is set

but will not function as a slave if omitted

#server-id = 2

The replication master for this slave - required

#master-host =

The username the slave will use for authentication when connecting

to the master - required

#master-user =

The password the slave will authenticate with when connecting to

the master - required

#master-password =

The port the master is listening on.

optional - defaults to 3306

#master-port =

Make the slave read-only. Only users with the SUPER privilege and the

replication slave thread will be able to modify data on it. You can

use this to ensure that no applications will accidently modify data on

the slave instead of the master

#read_only

#*** MyISAM Specific options

Size of the Key Buffer, used to cache index blocks for MyISAM tables.

Do not set it larger than 30% of your available memory, as some memory

is also required by the OS to cache rows. Even if you’re not using

MyISAM tables, you should still set it to 8-64M as it will also be

used for internal temporary disk tables.

key_buffer_size = 64M

Size of the buffer used for doing full table scans of MyISAM tables.

Allocated per thread, if a full scan is needed.

read_buffer_size = 8M

When reading rows in sorted order after a sort, the rows are read

through this buffer to avoid disk seeks. You can improve ORDER BY

performance a lot, if set this to a high value.

Allocated per thread, when needed.

read_rnd_buffer_size = 8M

MyISAM uses special tree-like cache to make bulk inserts (that is,

INSERT … SELECT, INSERT … VALUES (…), (…), …, and LOAD DATA

INFILE) faster. This variable limits the size of the cache tree in

bytes per thread. Setting it to 0 will disable this optimisation. Do

not set it larger than “key_buffer_size” for optimal performance.

This buffer is allocated when a bulk insert is detected.

bulk_insert_buffer_size = 16M

This buffer is allocated when MySQL needs to rebuild the index in

REPAIR, OPTIMIZE, ALTER table statements as well as in LOAD DATA INFILE

into an empty table. It is allocated per thread so be careful with

large settings.

myisam_sort_buffer_size = 64M

The maximum size of the temporary file MySQL is allowed to use while

recreating the index (during REPAIR, ALTER TABLE or LOAD DATA INFILE.

If the file-size would be bigger than this, the index will be created

through the key cache (which is slower).

#myisam_max_sort_file_size = 10G

If the temporary file used for fast index creation would be bigger

than using the key cache by the amount specified here, then prefer the

key cache method. This is mainly used to force long character keys in

large tables to use the slower key cache method to create the index.

#myisam_max_extra_sort_file_size = 10G

If a table has more than one index, MyISAM can use more than one

thread to repair them by sorting in parallel. This makes sense if you

have multiple CPUs and plenty of memory.

myisam_repair_threads = 1

Automatically check and repair not properly closed MyISAM tables.

myisam_recover

*** BDB Specific options ***

Use this option if you run a MySQL server with BDB support enabled but

you do not plan to use it. This will save memory and may speed up some

things.

skip-bdb

*** INNODB Specific options ***

Use this option if you have a MySQL server with InnoDB support enabled

but you do not plan to use it. This will save memory and disk space

and speed up some things.

#skip-innodb

Additional memory pool that is used by InnoDB to store metadata

information. If InnoDB requires more memory for this purpose it will

start to allocate it from the OS. As this is fast enough on most

recent operating systems, you normally do not need to change this

value. SHOW INNODB STATUS will display the current amount used.

#innodb_additional_mem_pool_size = 16M

InnoDB, unlike MyISAM, uses a buffer pool to cache both indexes and

row data. The bigger you set this the less disk I/O is needed to

access data in tables. On a dedicated database server you may set this

parameter up to 80% of the machine physical memory size. Do not set it

too large, though, because competition of the physical memory may

cause paging in the operating system. Note that on 32bit systems you

might be limited to 2-3.5G of user level memory per process, so do not

set it too high.

#innodb_buffer_pool_size = 2G

InnoDB stores data in one or more data files forming the tablespace.

If you have a single logical drive for your data, a single

autoextending file would be good enough. In other cases, a single file

per device is often a good choice. You can configure InnoDB to use raw

disk partitions as well - please refer to the manual for more info

about this.

#innodb_data_file_path = ibdata1:10M:autoextend

Set this option if you would like the InnoDB tablespace files to be

stored in another location. By default this is the MySQL datadir.

#innodb_data_home_dir =

Number of IO threads to use for async IO operations. This value is

hardcoded to 4 on Unix, but on Windows disk I/O may benefit from a

larger number.

#innodb_file_io_threads = 4

If you run into InnoDB tablespace corruption, setting this to a nonzero

value will likely help you to dump your tables. Start from value 1 and

increase it until you’re able to dump the table successfully.

#innodb_force_recovery=1

Number of threads allowed inside the InnoDB kernel. The optimal value

depends highly on the application, hardware as well as the OS

scheduler properties. A too high value may lead to thread thrashing.

#innodb_thread_concurrency = 16

If set to 1, InnoDB will flush (fsync) the transaction logs to the

disk at each commit, which offers full ACID behavior. If you are

willing to compromise this safety, and you are running small

transactions, you may set this to 0 or 2 to reduce disk I/O to the

logs. Value 0 means that the log is only written to the log file and

the log file flushed to disk approximately once per second. Value 2

means the log is written to the log file at each commit, but the log

file is only flushed to disk approximately once per second.

#innodb_flush_log_at_trx_commit = 1

Speed up InnoDB shutdown. This will disable InnoDB to do a full purge

and insert buffer merge on shutdown. It may increase shutdown time a

lot, but InnoDB will have to do it on the next startup instead.

#innodb_fast_shutdown

The size of the buffer InnoDB uses for buffering log data. As soon as

it is full, InnoDB will have to flush it to disk. As it is flushed

once per second anyway, it does not make sense to have it very large

(even with long transactions).

#innodb_log_buffer_size = 8M

Size of each log file in a log group. You should set the combined size

of log files to about 25%-100% of your buffer pool size to avoid

unneeded buffer pool flush activity on log file overwrite. However,

note that a larger logfile size will increase the time needed for the

recovery process.

#innodb_log_file_size = 256M

Total number of files in the log group. A value of 2-3 is usually good

enough.

#innodb_log_files_in_group = 3

Location of the InnoDB log files. Default is the MySQL datadir. You

may wish to point it to a dedicated hard drive or a RAID1 volume for

improved performance

#innodb_log_group_home_dir

Maximum allowed percentage of dirty pages in the InnoDB buffer pool.

If it is reached, InnoDB will start flushing them out agressively to

not run out of clean pages at all. This is a soft limit, not

guaranteed to be held.

#innodb_max_dirty_pages_pct = 90

The flush method InnoDB will use for Log. The tablespace always uses

doublewrite flush logic. The default value is “fdatasync”, another

option is “O_DSYNC”.

#innodb_flush_method=O_DSYNC

How long an InnoDB transaction should wait for a lock to be granted

before being rolled back. InnoDB automatically detects transaction

deadlocks in its own lock table and rolls back the transaction. If you

use the LOCK TABLES command, or other transaction-safe storage engines

than InnoDB in the same transaction, then a deadlock may arise which

InnoDB cannot notice. In cases like this the timeout is useful to

resolve the situation.

#innodb_lock_wait_timeout = 120

[mysqldump]

Do not buffer the whole result set in memory before writing it to

file. Required for dumping very large tables

quick

max_allowed_packet = 16M

[mysql]
no-auto-rehash

Only allow UPDATEs and DELETEs that use keys.

#safe-updates

[isamchk]
key_buffer = 128M
sort_buffer_size = 128M
read_buffer = 2M
write_buffer = 2M

[myisamchk]
key_buffer = 128M
sort_buffer_size = 128M
read_buffer = 2M
write_buffer = 2M

[mysqlhotcopy]
interactive-timeout

[mysqld_safe]

Increase the amount of open files allowed per process. Warning: Make

sure you have set the global system limit high enough! The high value

is required for a large number of opened tables

#open-files-limit = 8192

pid-file=/usr/local/mysql/mysqld.pid

rifai@rifai-System-Product-Name:/etc$ gedit tangorc

Config file for my package

TANGO_HOST=rifai-System-Product-Name:10000

rifai@rifai-System-Product-Name:/etc$ ifconfig
eth2 Link encap:Ethernet HWaddr 00:24:be:59:4a:a7
UP BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)
Interrupt:45

lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:16436 Metric:1
RX packets:4302 errors:0 dropped:0 overruns:0 frame:0
TX packets:4302 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:276516 (276.5 KB) TX bytes:276516 (276.5 KB)

ppp0 Link encap:Point-to-Point Protocol
inet addr:10.199.255.235 P-t-P:10.17.95.35 Mask:255.255.255.255
UP POINTOPOINT RUNNING NOARP MULTICAST MTU:1500 Metric:1
RX packets:19 errors:0 dropped:0 overruns:0 frame:0
TX packets:26 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:3
RX bytes:2523 (2.5 KB) TX bytes:1500 (1.5 KB)

wlan0 Link encap:Ethernet HWaddr 2c:81:58:e9:5f:51
UP BROADCAST MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)

Hi

We are facing problems while installing tango on the Ubuntu 14.04 (i.e. Ubuntu trusty).
We have followed the steps mentioned in the video on given link(https://youtu.be/f903EIbiv6w).

We are facing some dependency problems during installation,
In the end of installation it says,

[quote] Some packages could not be installed. This may mean that you have
requested an impossible situation or if you are using the unstable
distribution that some required packages have not yet been created
or been moved out of Incoming.
The following information may help to resolve the situation:

The following packages have unmet dependencies:
 libtango8-dev : Depends: libcos4-dev but it is not going to be installed
E: Unable to correct problems, you have held broken packages.[/quote]

We tried to fix the broken dependency with ‘sudo apt-get -f install’ ,but it shows everything clean.

[quote]
:~$ sudo apt-get -f install
Reading package lists… Done
Building dependency tree
Reading state information… Done
0 upgraded, 0 newly installed, 0 to remove and 0 not upgraded.[/quote]

We also tried to install libcos4-dev manually (sudo apt-get install libcos4-dev). But it also gives the another dependency problem.

Please guide us to resolve these issues.

Thanks & Regards
TCS GMRT Team

Strange. I did not have any issues on my recent installs on Ubuntu 15.04. I will try to find a 14.04 version to see if I can reproduce your problem. What hardware platform are you running on - Intel / ARM ?

Andy

Hi, I did not either have any issue of this kind during installation and following steps given in the video.
I will make some tests to check. Perhaps this could be linked to some choices before installation, or apt-get update ?

Can you do the following:

apt-cache policy libtango8-dev
apt-cache show libtango8-dev

So that we can have more info on where the problem might be.

Dear all,
you can download here an ubuntu 64b Tango virtual machine for easy testings

size is (only) 2.4 GB
unzip and install in virtualbox 64b (set bridged network)
pasword is xxx

tools :
Jive Astor Pogo Jdraw…
itango

home it helps

Raphael,

thanks a lot! For those of you who don’t speak French you must click on the button (see image below) with the title :

Valider et telecharger le fichier

which means validate and download the file.

Andy
